1. Introduction & Charateristics

SSS series super high-speed asynchronous servomotor is developed dedicated by REALLAND for high-speed main spindle application, which has a perfect characteristic in speed increasing and decreasing. It can achieve 12000-24000 r/min instantly and runs smoothly at high speed, so it is much better used in the spindle for drilling, tapping, milling machines.

Characteristic Curve

- From the static state to the rated speed (0-3000r/min), the motor can output rated torque of Ted.

- From the rated speed to max speed, the motor can keep the rated power, in this range, the maximum availabie Tmax can be approximately calculated by formula

Tmax [Nm] = Pmax [kW] * 9550 / N [r/min]

Pmax = Ped * (3Nmax-3000-N)/(Nmax-3000)

Option: Speed Sensor

Connection specification of encoder

2. Technical Specification

3. Product Code Explaination

4. Technical Parameters

5. Dimensions

• SSS05 IMB5

• SSS07 IMB5

1. Introduction & Charateristics

SST series super high-speed PM synchronous servomotor is developed dedicated by REALLAND for high-speed main spindle application, which has a perfect characteristic in speed increasing and decreasing. It can achieve 12000-24000 r/min instantly and runs smoothly at high speed. Compared with the asynchronous motor, it has the advantages of greater acceleration torque, faster dynamic response, and shorter processing time, so it is a better choice for the high speed spindle of the drilling, milling and tapping machine tools.

Option: Speed Sensor

Connection specification of encoder

2. Technical Specification

3. Product Code Explaination

4. Technical Parameters

5. Characterisitc Curve

6. Dimensions

• SST05 IMB5

Product Series Catalog

【Product Series Catalog: Including technical specifications, model description, basic parameters of all standard models】

———————————————————————————————

SSS/SST Motor Series Catalog .pdf
